Explosion-Proof Camera
Your Professional Explosion-Proof Camera Supplier
Our goal is to become your true partner in the field of device in China. Anhui Hengtai Electrical Technology Co., Ltd. is a national-level high-tech enterprise. We have a skilled engineering team dedicated to refining every stage, from product development and process improvement to production oversight, ensuring every product delivered meets rigorous quality and performance standards. The price is competitive and the product is quality-assured, which is a good choice for your long-term cooperation.
Why Choose Us
Production equipment
We have advanced production equipment, mainly including: CNC lathes, machining centers, laser cutting machines, automatic online coding machines, shearing machines, laser welders, welding robots, etc. more than 50 sets.
Our certificates
We have 116 safety standard certificates, 28 authorized national patents, 6 software copyright certificates, and 20 scientific and technological achievement registration certificates.
Production market
Our products are very popular in the market, and our sales areas are spread across many countries, mainly including Germany, Vietnam and Mongolia.
Our services
All products are under the condition of correct installation, normal use and proper maintenance, and enjoy a one-year warranty from the date of acceptance of the installation and commissioning of the entire set of equipment. During the warranty period, the supplier will solve any quality problems of the main components free of charge.
Product Description
|
Type |
Flame-proof Anti-explosion Camera |
|
Sensor |
1/3" AHD |
|
Resolution |
1920x1080 pixels |
|
TV line |
2.0MP |
|
Lens |
3.6mm |
|
Min illumination |
0Lux (LED ON) |
|
IR led |
24pcs |
|
Night Vision distance |
35ft |
|
Waterproof |
IP69K |
|
View angle |
90° |
|
Power voltage |
12-24V |
|
Operation Temp |
-20℃ to +70℃ |
Benefits of Explosion-Proof Camera
Durability in Extreme Conditions
In hazardous environments, cameras must withstand extreme temperatures, dust, and water exposure. Explosion-proof cameras are engineered with reinforced housings and weatherproof seals, allowing them to function in harsh conditions without failure.
Cost Efficiency
Explosion-proof cameras typically have a longer lifespan due to their robust design, reducing the need for frequent replacements. They also require less maintenance, making them a cost-effective solution over time.
High-Quality Imaging and Zoom Capability
Explosion-proof cameras provide high-definition video, even in low-light conditions. Many models include zoom features that allow for detailed inspection from a safe distance.
Real-Time Alerts
For enhanced safety, explosion-proof cameras often come integrated with sensors that trigger alerts when abnormal conditions are detected, such as heat or motion. These real-time notifications allow businesses to respond quickly to potential hazards.
Flexible Integration
Explosion-proof cameras can be integrated with a wide range of security systems, such as access control, fire alarms, and intrusion detection. This integration provides a comprehensive safety network, streamlining operations in hazardous environments. cameras are compatible with various security platforms, ensuring seamless integration for robust site security.
Specification
|
Product name |
Explosion-proof camera |
|
Lens Type |
3.6MM Explosion-proof lens |
|
Network |
NVR |
|
Feature |
Two-way Voice |
|
Power Supply |
DC12V |
|
POE |
Support POE Power |
|
Night vision |
5-20m |
|
Customized |
Customized logo, OEM, ODM |
|
Video |
|
|
System |
High-performance DSP, Hisi3516CV300+Sony 290 |
|
Sensor |
2.0M Pixel 1/2.8" CMOS Sensor |
|
Output resolution |
1920(H)×1080(V) |
|
WDR |
Support |
|
D/N Mode |
Auto switching,black and white vide and IR cut action linkage |
|
Illumination |
Color 1.0Lux@F1.2,Black 0.1 Lux@F1.2 |
|
Video processing |
H.264 video compression, dual streaming |
|
AVI format, 0.1M~6Mpbs adjustable; |
|
|
Video Output |
Main streaming:1920*1080, 1280*960, 1280×720,1024×768,1280×720; |
|
Frame rate |
2.0MP 25/30 frame(full real time),support 1~30frame/seconds adjustable |
|
Network interface |
RJ45 ethernet,10/100M;RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP protocol supported |
|
Access Protocol |
Standard ONVIF Protocol, Support third party access; PC; |
|
Support IE6.0 and aboveSmartphone |
|
|
Support Android\iPhone |
|
|
Lens |
|
|
Lens |
4/6mm lens for optional |
|
IR distance |
30-60M IR Range, |
|
Function |
|
|
Function |
Support WEB configuration, OSD,real-time video transmission |
|
Support motion detection |
|
|
Support front end storage ,playback and download |
|
|
Support uniform client and platform system application |
|
|
Support complete SDK for second development. |
|
|
Housing Material |
|
|
Explosion-proof housing |
304/316 stainless steel, polishing passivation treatment, Rust corrosion resistance, never fade |
|
Ingress Protection |
IP68 |
|
Interface spec |
G-1/2" |
|
Method of installation |
Bracket mount |
|
Atex Mark |
II 2G Ex db IIC T6 Gb, II 2D Ex tb IIIC(85 degree) Db |
|
IEC Mark |
Ex dIIC T6 Gb/DIP A20 TA, T6 |
|
Normal |
|
|
Power supply |
DC12V/POE(optional) |
|
Working Current |
<=1A |
Application of Explosion-Proof Camera
Oil and Gas Industry
The Oil and gas industry is fraught with dangers where flammable gases are too common due to high-temperature environments. Installing an explosion proof camera can provide a crucial line of defense in such areas.
Chemical Plants
Chemical plants often deal with volatile chemicals, which can be hazardous if not monitored properly. Humans can not monitor some areas in these plants due to the high risk of exposure to harmful chemicals.
Mining Industry
The presence of combustible dust and gases makes mining sites extremely dangerous and therefore, it is very difficult to monitor the sites. Besides, Mining operations are at constant risk of explosions, making installation of flameproof cameras a vital need.
Pharmaceuticals
Pharmaceutical plants handle a variety of volatile substances and operate under stringent regulatory standards to ensure safety and product integrity. Many areas within these facilities pose significant risks due to the presence of flammable chemicals, making human monitoring challenging.
Food And Beverage Processing
Food and beverage processing plants deal with a variety of flammable materials and must adhere to strict hygiene standards. Certain areas pose risks that make human monitoring impractical.
Aerospace Industry
The aerospace industry involves manufacturing and testing with highly volatile materials and complex processes. These places require stringent safety measures as the risk of explosions and the need for precision make human monitoring difficult.
Transportation&Payment
FAQ
As one of the most professional explosion-proof camera manufacturers in China, we're featured by providing high quality products for mining communication system and mining automation equipment. Welcome to buy customized explosion-proof camera from our factory.
